Product Summary

The NLCV32T-4R7M-PF is an inductor power. The device operates as protection from brown-out conditions when the system supply voltage drops below a safe operating level.

Parametrics

NLCV32T-4R7M-PF absolute maximum ratings: (1)Inductance: 4.7 μH; (2)Inductance tolerance: ± 20%; (3)Q typ.: 15; (4)Test frequency L, Q: 7.96 MHz; (5)Self-resonant frequency min.: 46 MHz; (6)DC resistance ± 30%: 0.2 MHz; (7)Rated current max.: 620 mA.

Features

NLCV32T-4R7M-PF features: (1)a renewed version of NLC322522; (2)has good heat durability that withstands lead-free compatible reflow soldering conditions; (3)Lead-free material; (4)used for the plating on the terminal; (5)the same as the previous NL series; (6)realize excellent connection reliability; (7)Highly heat resistant thermoplastic resin is used to form the exterior package.

Diagrams

NLCV32T-4R7M-PF package dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
NLCV32T-4R7M-PF
NLCV32T-4R7M-PF
TDK
Power Inductors 4.7 UH 20%
Data Sheet
0-1: $0.17
1-10: $0.16
10-50: $0.13
50-100: $0.11
NLCV32T-4R7M-PFR
NLCV32T-4R7M-PFR
TDK
Power Inductors 4.7uH 20%
Data Sheet
0-1: $0.20
1-10: $0.16
10-100: $0.13
100-500: $0.10
