Product Summary

The MMBT3906LT1G is a General Purpose Transistor.

Parametrics

MMBT3906LT1G absolute maximum ratings: (1) Collector Emitter Voltage VCEO: -40Vdc; (2) Collector Base Voltage VCBO: -40Vdc; (3) Emitter Base Voltage VEBO: -5.0Vdc; (4) Collector Current Continuous IC: -200mAdc.

Features

MMBT3906LT1G feature: (1)Thermal Resistance Junction to Ambient RθJA: 556 ℃/W; (2)Thermal Resistance Junction to Ambient RθJA: 417 ℃/W; (3)Junction and Storage Temperature TJ, Tstg: -55℃ to +150℃; (4)Pb-Free Packages are Available.

Diagrams

MMBT3906LT1G package dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MMBT3906LT1G
MMBT3906LT1G

ON Semiconductor

Transistors Bipolar (BJT) 200mA 40V PNP

Data Sheet

0-1: $0.07
1-25: $0.06
25-100: $0.03
100-500: $0.02
