Product Summary

The BC868,115 is an NPN medium power transistor in a SOT89 plastic package.

Parametrics

BC868,115 absolute maximum ratings: (1)Collector-Base Voltage VCBO: 32 V; (2)Collector-Emitter Voltage VCEO: 20 V; (3)Emitter-Base Voltage VEBO: 5 V; (4)Peak Pulse Current ICM: 2 A; (5)Continuous Collector Current IC: 1 A; (6)Power Dissipation at Tamb =25℃ Ptot: 1 W; (7)Operating and Storage Temperature Range Tj:Tstg: -65℃ to +150℃.

Features

BC868,115 features: (1)suitable for general af applications and class B audio output stages upto 3W; (2)high hFE and low saturation voltage; (3)partmarking details – CAC.

Diagrams

BC868,115 package dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BC868,115
BC868,115
NXP Semiconductors
Transistors Bipolar (BJT) NPN 20V 1A
Data Sheet
0-1: $0.36
1-25: $0.32
25-100: $0.27
100-250: $0.24
